key Features

- 8th/9th Generation Intel Core I9/Core I7/Core I5/Core I3/Pentium /Celeron Processor
- Intel Chip Set Q370
- Up To 64gb Unbuffered Non-Ecc Udimm, Ddr4-2666mhz, In 4 Dimm Slots
- 1 Pci-E 3.0 X16
- 1 Pci-E 3.0 X1
- 2 Pci-E 3.0 X4
- M.2 Interface: 1 Pci-E 3.0 X4
- M.2 Form Factor: 2242/2280/22110
- M.2 Key: M-Key
- 1 Dvi-D + 1 Hdmi + 1 Display Port + 1 Edp (Embedded Displayport)
- 3 Independent Displays
- Intel® Q370 Controller For 6 Sata3 (6 Gbps) Ports; Raid 0,1,5,10
- Single Lan With Intel® Ethernet Controller I210-At
- Single Lan With Intel® Phy I219lm Lan Controller
